Serie YC Codice L (µH) DCR (Ω) DCI (A) Codice L (µH) DCR(Ω) DCI (A)
serie: YC Adimpex ±20% max. max. Adimpex ±20% max. max.
FJA38010 FJA38112 120 0.66 0.52
Serie YC 2 10 0.061 1.84
serie: YC12
FJA38012 12 0.063 1.71 FJA38115 150 0.88 0.46
Serie YC 2
serie: YC12 FJA38015 15 0.081 1.47 FJA38118 180 0.98 0.42

FJA38018 18 0.091 1.31 FJA38122 220 1.17 0.36

FJA38022 22 0.110 1.23 FJA38127 270 1.64 0.34

FJA38027 27 0.150 1.12 FJA38133 330 1.86 0.32

FJA38033 33 0.170 0.96 FJA38139 390 2.85 0.29

FJA38039 39 0.230 0.91 FJA38147 470 3.01 0.26

FJA38047 47 0.260 0.88 FJA38156 560 3.62 0.23

FJA38056 56 0.350 0.75 FJA38168 680 4.63 0.22

FJA38068 68 0.380 0.69 FJA38182 820 5.20 0.20

FJA38082 82 0.450 0.61 FJA38210 1000 6.00 0.18

FJA38110 100 0.610 0.60

DCI: valore della corrente in corrispondenza di una riduzione di induttanza pari al
0%

Codice L (µH) DCR (Ω) DCI (A) Codice L (µH) DCR DCI (A)
Adimpex ±20% max. max. Adimpex ±20% (Ω) max.
FJA46082 max. 1.95
FJA46.12 1.2 0.0700 9.80 82 0.12

FJA46.18 1.8 0.0115 8.00 FJA46110 100 0.15 1.70

FJA46.33 3.3 0.0135 7.50 FJA46112 120 0.17 1.60

FJA46.47 4.7 0.0158 6.80 FJA46115 150 0.19 1.42

FJA46010 10 0.0216 5.40 FJA46118 180 0.25 1.30

FJA46012 12 0.0243 4.90 FJA46122 220 0.35 1.16

FJA46015 15 0.0270 4.50 FJA46127 270 0.39 1.06

FJA46018 18 0.0392 3.90 FJA46133 330 0.48 0.95

FJA46022 22 0.0432 3.60 FJA46139 390 0.54 0.88

FJA46027 27 0.0459 3.40 FJA46147 470 0.79 0.79

FJA46033 33 0.0648 3.00 FJA46156 560 0.87 0.73

FJA46039 39 0.0729 2.75 FJA46168 680 1.00 0.67

FJA46047 47 0.0770 2.50 FJA46182 820 1.20 0.60

FJA46056 56 0.0970 2.35 FJA46210 1000 1.30 0.55

FJA46068 68 0.1000 2.10

DCI: valore della corrente in corrispondenza di una riduzione di induttanza pari al
%

Codice Adimpex L (µH) ±20% DCR (Ω) max. DCI (A) max. @ ∆L
FJA47.56 5.6 0.014 6.0 @ 25%
FJA47010 10 0.022 5.7 @ 20%
FJA47015 15 0.040 5.5 @ 20%
FJA47018 18 0.060 5.0 @ 25%
FJA47022 22 0.068 5.0 @ 25%
FJA47033 33 0.080 5.0 @ 25%
FJA47047 47 0.080 3.0 @ 25%
FJA47068 68 0.069 2.8 @ 20%
FJA47110 100 0.180 3.0 @ 25%
FJA47115 150 0.180 2.0 @ 25%
FJA47122 220 0.330 1.5 @ 20%
FJA47133 330 0.430 1.0 @ 10%
FJA47147 470 0.560 1.0 @ 20%
FJA47168 680 0.800 0.8 @ 20%
FJA47210 1000 1.300 0.8 @ 30%
