Page 78 - Catalogo Adimpex 2016
P. 78
Serie YC Codice L (µH) DCR (Ω) Irms Codice L (µH) DCR (Ω) Irms
serie: YC080 Adimpex ±20% max. (A) Adimpex ±20% max. (A)
max. max.
Serie YC 2 FJ124.10 1.0 0.009 6.80 FJ124033 33 0.100 2.10
serie: YC120 FJ124.15 1.5 0.010 6.40 FJ124047 47 0.140 1.80
FJ124.22 2.2 0.012 6.10 FJ124056 56 0.162 1.70
Serie YC FJ124.33 3.3 0.015 5.40 FJ124068 68 0.200 1.50
serie: YC0 0 FJ124.47 4.7 0.018 4.80 FJ124110 100 0.280 1.30
FJ124.56 5.6 0.027 4.60 FJ124115 150 0.400 1.00
78 FJ124.68 6.8 0.027 4.40 FJ124122 220 0.610 0.80
FJ124010 10 0.038 3.90 FJ124133 330 1.020 0.60
FJ124015 15 0.049 3.10 FJ124147 470 1.270 0.50
FJ124022 22 0.085 2.70 FJ124168 680 2.020 0.40
FJ124027 27 0.100 2.10 FJ124210 1000 3.000 0.30
Ir s: valore della corrente in corrispondenza di un au ento di te peratura di 0 C
Codice L (µH) DCR (Ω) Irms (A) Codice L (µH) DCR (Ω) Irms (A)
Adimpex ±20% max. max. Adimpex ±20% max. max.
FJ128.10 FJ128056
FJ128.15 1.0 0.009 8.60 FJ128068 56 0.120 2.40
FJ128.22 1.5 0.010 8.00 FJ128082 68 0.130 2.30
FJ128.33 2.2 0.014 7.10 FJ128110 82 0.200 2.00
FJ128.47 3.3 0.018 6.20 FJ128115 100 0.190 1.80
FJ128.56 4.7 0.019 5.80 FJ128122 150 0.250 1.50
FJ128010 5.6 0.020 5.30 FJ128133 220 0.380 1.20
FJ128012 10 0.031 4.30 FJ128147 330 0.560 1.00
FJ128015 12 0.032 4.00 FJ128168 470 0.850 0.82
FJ128022 15 0.036 4.00 FJ128182 680 1.100 0.72
FJ128033 22 0.047 3.50 FJ128210 820 1.500 0.68
FJ128047 33 0.066 3.00 1000 1.800 0.56
47 0.086 2.60
Ir s: valore della corrente in corrispondenza di un au ento di te peratura di 0 C
Codice L (µH) DCR (Ω) DCI (A) Codice L (µH) DCR (Ω) DCI (A)
Adimpex ±20% max. max. Adimpex ±20% max. max.
FJA35.10 FJA35047
1.0 0.020 2.80 47 0.221 0.75
FJA35.15 1.5 0.024 2.59 FJA35056 56 0.306 0.64
FJA35.22 2.2 0.028 2.38 FJA35068 68 0.345 0.60
FJA35.33 3.3 0.034 2.14 FJA35082 82 0.390 0.57
FJA35.47 4.7 0.039 1.96 FJA35110 100 0.432 0.50
FJA35.68 6.8 0.050 1.79 FJA35112 120 0.440 0.47
FJA35010 10 0.055 1.63 FJA35115 150 0.730 0.40
FJA35012 12 0.073 1.42 FJA35118 180 0.780 0.39
FJA35015 15 0.081 1.33 FJA35122 220 0.940 0.33
FJA35018 18 0.102 1.15 FJA35127 270 1.250 0.31
FJA35022 22 0.115 1.09 FJA35133 330 1.400 0.27
FJA35027 27 0.159 0.91 FJA35139 390 1.520 0.27
FJA35033 33 0.182 0.84 FJA35147 470 1.700 0.25
FJA35039 39 0.199 0.80 FJA35156 560 2.390 0.22
DCI: valore della corrente in corrispondenza di una riduzione di induttanza pari al
10%
