Bobine Toroidali Antidisturbo Verticali Compensate
Current Compensated Interference Suppression Chokes

CARATTERISTICHE FEATURES

Correnti nominali: 0.5 ÷ 8 A Nominal current: 0.5 ÷ 8 A
Induttanza Nominale: 05 ÷ 39 mHr Nominal Inductance: 05 ÷ 39 mHr
Max. tensione di lavoro: Ur (vedere tabelle) Max. operating table: Ur (See table)
Tensione di test: Test voltage:
1.8 KV AC / 2sec. avvolgimento-avvolgimento; 1.8 KV AC / 2sec. wdg to wdg;
1.5 KV AC per serie 6210; 1.5 KV AC for 6210 series;
2.0 KV AC / 2sec avvolgimento-ambiente 2.0 KV AC / 2sec wdg to ambient
Frequenza di lavoro: DC fino a 400hz Operating frequency: DC to 400hz
Classe climatica: 25/100/21 secondo le IEC 60068-1 Climatic class: 25/100/21 as IEC 60068-1
Infiammabilità: UL 94-V0 Infiammability: UL 94-V0

Case tipo 10

Codice Adimpex IN (A) LN (mH) RCu (mΩ) Ploss fres. UR
(W) (MHz) (VAC)
FC000030 @ θ 40°C -30/+50 % ± 10 %
FC000032 0.3 approx 250
FC000034 0.5 2 x 3.9 2 x 500 0.4 250
0.9 2 x 2 2 x 240 0.4 1.2 250
2 2 x 0.5 2 x 50
1.6

4.5

serie: CCSP-6210
Case tipo 14

Codice Adimpex IN (A) LN (mH) RCu (mΩ) Ploss fres. UR
(W) (MHz) (VAC)
FC000048 @ θ 40°C -30/+50 % ± 10 %
FC000050 0.4 approx 250
FC000052 0.63 2 x 10 2 x 570 0.5 250
1 2 x 3.9 2 x 250 0.5 0.5 250
2 2x1 2 x 65
1.2

2.5

serie: CCSP-6214
Case tipo 22

Codice Adimpex IN (A) LN (mH) RCu (mΩ) Ploss fres. UR
-30/+50 % ± 10 % (W) (MHz) (VAC)
FC000060 @ θ 40°C
FC000062 2 x 22 2 x 500 1 approx 250
FC000064 1 2 x 5.6 2 x 140 1.1 250
2 2 x 1.5 2 x 36 1.2 0.3 250
4
0.6

1.5

serie: CCSP-6222
Case tipo 33

Codice Adimpex IN (A) LN (mH) RCu (mΩ) Ploss fres. UR
@ θ 40°C -30/+50 % ± 10 % (W) (MHz) (VAC)
FC000066
FC000068 1 2 x 33 2 x 700 1.4 approx 250
FC000070 2 2 x 6.8 2 x 150 1.2 250
6 2x2 2 x 24 1.8 0.3 250

0.5

1.2

serie: CCSP-6233
