ABC040002A Pin no symbol Pin no symbol
ABC040004A 1 VSS 9 DB2
ABC040004C 2 VDD 10 DB3
3 Vo 11 DB4
4 RS 12 DB5
5 R/W 13 DB6
6 E 14 DB7
7 DB0 15 LEDA
8 DB1 16 LEDK

Pin no symbol Pin no symbol
1 VSS 10 DB2
2 VDD 11 DB3
3 Vo 12 DB4
4 RS 13 DB5
5 R/W 14 DB6
6 E1 15 DB7
7 E2 16 NC
8 DB0 17 LEDA
9 DB1 18 LEDK

Pin no symbol Pin no symbol Pin no symbol
1 NC 10 VSS 19 DB4
2 NC 11 DB0 20 LEDK
3 E2 12 VSS 21 DB5
4 NC 13 DB1 22 VDD
5 R/W 14 VSS 23 DB6
6 NC 15 DB2 24 VDD
7 RS 16 VSS 25 DB7
8 VSS 17 DB3 26 LEDA
9 E1 18 VSS
