ABC02000 Pin no symbol Pin no symbol
ABC02000 G 1 VSS 10 DB3
ABC02 002A 2 VDD 11 DB4
3 Vo 12 DB5
198 4 RS 13 DB6
5 R/W 14 DB7
6 E 15 LEDA
7 DB0 16 LEDK
8 DB1 17 NC
9 DB2 18 NC
Pin no symbol Pin no symbol
1 VSS 10 DB3
2 VDD 11 DB4
3 Vo 12 DB5
4 RS 13 DB6
5 R/W 14 DB7
6 E 15 LEDA
7 DB0 16 LEDK
8 DB1 17 NC
9 DB2 18 NC
Pin no symbol Pin no symbol
1 VSS 9 DB2
2 VDD 10 DB3
3 Vo 11 DB4
4 RS 12 DB5
5 R/W 13 DB6
6 E 14 DB7
7 DB0 15 LEDA
8 DB1 16 LEDK
