AGC016002A Pin no symbol Pin no symbol
AGC016004A 1 VSS 10 DB3
AGG128064C 2 Vo 11 DB4
3 VDD 12 DB5
208 4 RS 13 DB6
5 R/W 14 DB7
6 E
7 DB0
8 DB1
9 DB2
Pin no symbol Pin no symbol
1 RS 16 V3
2 17 V2
3 RW RW 18 V1
4 E RD 19 V0
5 CSB 20 VR
6 DB7 21
7 DB6 22 VOUT
8 DB5 23 CAP2-
9 DB4 24 CAP2+
10 DB3 25 CAP1-
11 DB2 26 CAP1+
12 DB1 27
13 DB0 28 PS
14 VDD 29 IF
15 VSS 30 MI
V4 RESET
NC
Pin no symbol Pin no symbol
1 /CS1 18 C3-
2 /RES 19 C1+
3 A0 20 C1-
4 21 C2-
5 WR(RD) 22 C2+
6 RD(E) 23 C4-
7 DB0 24 VRS
8 DB1 25 V1
9 DB2 26 V2
10 DB3 27 V3
11 DB4 28 V4
12 DB5 29 V5
13 DB6 30 VR
14 DB7 31 C86
15 VDD 32 P/S
16 VSS 33 HPM
17 VOUT 34 IRS
C5-
