Dip Switch P H | P H Dip Switches

CARATTERISTICHE FEATURES

Portata: 25mA, 24V DC Rating: 25mA, 24V DC.
Contact resistance: 100mΩ max.
Resistenza di contatto: 100mΩ max. Insulation resistance: > 1000MΩ at 100V DC
Dielectric withstanding: 500V DC for 1 minute
Resistenza d'isolamento: > 1000MΩ a 100V DC Operating force: 800 gr. max.
Stro e: 0. mm
Rigidità dielettrica: 500V DC per 1 minuto Operating life (cycles): 2000
Actuator: T U 4V-0 white
Forza: 800gr. max. Cover: T U 4V-0 lac

Corsa: 0. mm ase: T U 4V-0 lac
Contact: copper alloy, gold plating
Vita operativa (cicli): 2000 Terminal: rass, tin plating

Attuatore: P T 4V-0 ianco

C iusura: P T 4V-0 nero

ase: P T 4V-0 nero

Contatti: lega di rame, dorato

Terminali: ottone, stagnato

Se ie S Codice Adimpex n° posizioni A (mm) package
KV000101 01 3.84 tube 130 pcs
serie: KV000102 02 6.08 tube 82 pcs
Se ie S top tape KV000103 03 8.92 tube 56 pcs
seale KV000104 04 11.16 tube 45 pcs
KV000105 05 13.70 tube 36 pcs
serie: KV000106 06 16.24 tube 30 pcs
Se ie PM KV000107 07 19.08 tube 26 pcs
KV000108 08 21.32 tube 23 pcs
serie: KV000109 09 24.16 tube 20 pcs
KV000110 10 26.40 tube 19 pcs
KV000112 12 31.48 tube 16 pcs

Codice Adimpex n° posizioni A (mm) package
KV002101 01 3.84 tube 130 pcs
KV002102 02 6.08 tube 82 pcs
KV002103 03 8.92 tube 56 pcs
KV002104 04 11.16 tube 45 pcs
KV002105 05 13.70 tube 36 pcs
KV002106 06 16.24 tube 30 pcs
KV002107 07 19.08 tube 26 pcs
KV002108 08 21.32 tube 23 pcs
KV002109 09 24.16 tube 20 pcs
KV002110 10 26.40 tube 19 pcs
KV002112 12 31.48 tube 16 pcs

Codice Adimpex n° posizioni A (mm) package
KV 05002 02 4.89 tube 95 pcs
KV 05004 04 10.06 tube 47 pcs
KV 05006 06 15.14 tube 31 pcs
KV 05008 08 20.22 tube 23 pcs
KV 05010 10 25.30 tube 18 pcs
