P. 495
Dip Switch SMD | SMD Dip Switch
CARATTERISTICHE FEATURES
Portata: 25mA, 24V DC Rating: 25mA, 24V DC.
Resistenza di contatto: 100mΩ max. Contact resistance: 100mΩ max.
Resistenza d'isolamento: > 100MΩ a 500V DC Insulation resistance: > 100MΩ at 500V DC
Rigidità dielettrica: 500V DC per 1 minuto Dielectric withstanding: 500V DC for 1 minute
Forza: 600gr. max. Operating force: 600 gr. max.
Corsa: 0. mm Stro e: 0. mm
Vita operativa (cicli): 2000 Operating life (Cycles): 2000
Attuatore: n lon 4V-0 ianco Actuator: nylon U 4V-0 white
C iusura: n lon 4V-0 nero Cover: nylon U 4V-0 lac
ase: n lon 4V-0 nero ase: nylon U 4V-0 lac
Contatti: lega di rame, dorato Contact: copper alloy, gold plating
Terminali: ottone, dorato Terminal: rass, gold plating
Se ie M Codice Adimpex n° posizioni A (mm) B (mm) package
serie: KV005002 02 6.02 2.54 tube 84 pcs
KV005003 03 8.56 5.08 tube 59 pcs
KV005004 04 11.10 7.62 tube 45 pcs
KV005005 05 13.64 10.16 tube 37 pcs
KV005006 06 16.18 12.70 tube 31 pcs
KV005007 07 16.18 12.70 tube 27 pcs
KV005008 08 21.26 17.78 tube 24 pcs
KV005009 09 23.80 20.32 tube 21 pcs
KV005010 10 26.34 22.86 tube 19 pcs
KV005012 12 31.42 27.94 tube 16 pcs
Se ie H Codice Adimpex n° posizioni A (mm) B (mm) package
serie: H KV000002 02 6.02 2.54 tube 84 pcs
KV000003 03 8.56 5.08 tube 59 pcs
KV000004 04 11.10 7.62 tube 45 pcs
KV000005 05 13.64 10.16 tube 37 pcs
KV000006 06 16.18 12.70 tube 31 pcs
KV000007 07 18.72 15.24 tube 27 pcs
KV000008 08 21.26 17.78 tube 24 pcs
KV000009 09 23.80 20.32 tube 21 pcs
KV000010 10 26.34 22.86 tube 19 pcs
KV000012 12 31.42 27.94 tube 16 pcs
Dip Switch i State | i State Dip Switches
CARATTERISTICHE FEATURES
Portata: 25mA, 24V DC Rating: 25mA, 24V DC.
Contact resistance: 100mΩ max.
Resistenza di contatto: 100mΩ max. Insulation resistance: > 1000MΩ at 100V DC
Dielectric withstanding: 500V DC for 1 minute
Resistenza d'isolamento: > 1000MΩ a 100V DC Operating force: 800 gr. max.
Stro e: 0. mm
Rigidità dielettrica: 500V DC per 1 minuto Operating life (cycles): 2000
Actuator: T U 4V-0 white
Forza: 800gr. max. Cover: T U 4V-0 lac
Corsa: 0. mm ase: T U 4V-0 lac
Contact: copper alloy, gold plating
Vita operativa (cicli): 2000 Terminal: rass, tin plating
Attuatore: P T 4V-0 ianco
C iusura: P T 4V-0 nero
ase: P T 4V-0 nero
Contatti: lega di rame, dorato
Terminali: ottone, stagnato
Se ie
Codice Adimpex n° posizioni A (mm) package
KV000004 04 11.76 tube 46 pcs
KV000005 05 14.30 tube 37 pcs
KV000008 08 21.92 tube 31 pcs
KV000010 10 27.00 tube 24 pcs
serie:
