P. 20
Resistori Metal la e | Metal la e Film Fixed Resistors
M R-25 D (mm) L (mm) d (mm) H (mm)
M R-50 2.20 6.50 0.54 28.0
M R-100 3.00 9.50 0.54 28.0
M R-200 4.00 11.5 0.65 28.0
M R-300 5.00 15.5 0.75 28.0
6.00 17.5 0.75 28.0
Serie M R Tipo Tolleranza Potenza Max. tensione Max. tensione Rigidità Picchi di tensione Gamma T.C.R.
Codice Adimpex MGR-25 (70°C) di lavoro di sovraccarico dielettrica di valori ≤ ±200 ppm/°C
AMG04zxx 100 k ÷ 100M:
± 5% 1/4 W 500 V 700 V 500 V 10000 V 1 kΩ ÷ 100 MΩ
AMG05zxx MGR-50 ± 5% 1/2 W 700 V 1000 V 700 V 100 k ÷ 100M: 1 kΩ ÷ 100 MΩ ≤ ±200 ppm/°C
10000 V
AMG10zxx MGR-100 ± 5% 1W 1000 V 1400 V 700 V 1 kΩ ÷ 100 MΩ ≤ ±200 ppm/°C
100 k ÷ 100M:
AMG20zxx MGR-200 ± 5% 2W 1000 V 1400 V 700 V 10000 V 1 kΩ ÷ 100 MΩ ≤ ±200 ppm/°C
AMG30zxx MGR-300 ± 5% 3W 1000 V 1400 V 700 V 100 k ÷ 100M: 1 kΩ ÷ 100 MΩ ≤ ±200 ppm/°C
10000 V
100 k ÷ 100M:
10000 V
Come ordinare: x x
z prima cifra seconda cifra
significativa significativa
numero di zeri
20
