Photocouplers

Absolute Maximum Ratings Electrical Characteristics

Tipo Schema Safety Features Isolation Collector CTR (%) V(sat) (V) Response Time (µs)
Standards Voltage (AC) Emitter
Viso (Vrms) Voltage IF=±1mA - VCE=5V IF=±20mA - IC=1mA VCE=2V - IC=2mA - RL=100Ω
VCEO (V)
min. max. typ. max. Tr Tf

KB814 UL no.E225308 & High isolation voltage 5000 35 20 300 0.1 0.2 4 3
VDE0884. AC input
response
NO.40006364

UL NO.E225308 &
KB817 VDE0884. High isolation voltage 5000 35 50 600 0.1 0.2 4 3

NO.40006364

KB817-B UL NO.E225308 & High isolation voltage 5000 35 50 600 0.1 0.2 4 3
VDE0884. SMD type

NO.400006364

KB814 - KB817 KB817-B

serie: KB814 - KB817 serie: KB817-B

Codice Tipo Codice Adimpex
Adimpex OL300343
OL300020 KB-
814
OL300340 KB-
817

Retroilluminatori | Back Light

Retroilluminatore Codice Adimpex Colore λD Tipo di Intensità luminosa (mcd) Angolo di
9.2 x 1.9 x 1.5 mm (nm) lente min. typ. @mA visione
OH921510 2θ1/2
KA-9219/2SESK Arancio 601 water clear 200 300 20 100°

OH921512 Rosso 630 water clear 80 150 20 100°
KA-9219/2SURSK
Verde 570 water clear 55 120 20 100°
OH921515
KA-9219/2CGSK Verde 525 water clear 500 900 20 100°

OH921520 Giallo 590 water clear 120 250 20 100°
KA-9219/2ZGS
serie: KA-9219/2 Blu 465 water clear 120 250 20 100°
OH921525
KA-9219/2SYSK

OH921528
KA-9219/2QBS-D
